S&B 227 LITRE REPLACEMENT LONG RANGE FUEL TANK FOR 2017-2025 FORD POWERSTROKE 6.7L F250 & F350 CREW CAB SHORT BED

S&B 227 LITRE REPLACEMENT LONG RANGE FUEL TANK FOR 2017-2025 FORD POWERSTROKE 6.7L F250 & F350 CREW CAB SHORT BED

10-1004

$3,980.00 AUD
$3,980.00 AUD
Sale Sold out
Taxes included.

227 LITRE REPLACEMENT LONG RANGE FUEL TANK FOR 2017-2025 FORD POWERSTROKE 6.7L CREW CAB SHORT BED



Important Notes: The nozzle at high-flow fuel stations (truck stops) will not be able to fill automatically.

This tank holds approximately 60 gallons of fuel. The float's empty position in the S&B Tank is the same as the OEM tank. Since the bottom surface area on the S&B Tank is larger, the 60-gallon tank with have a greater fuel reserve.

According to the Ford TSB 17-0046. If your truck has a build date prior to 3-20-17. Replace the fuel Level Sender Resistor Card Assembly with Ford part # HC3Z-9A299-N.

If you purchased this tank prior to 1/1/2024, it won't fit 2023+High Output models as a revision was made to accommodate the fuel line going to the DPF.

ALMOST DOUBLES YOUR RANGE.

S&B's 60-gallon fuel tank directly replaces the OEM 34-gallon tank without any cutting, drilling, or special modifications. This makes for a trouble-free, faster installation process. S&B's replacement fuel tank holds 5 more gallons than competitor tanks, allowing you to save time, go further, and get more out of your truck! Go big or go home!

PRODUCT DETAILS

COMPATIBLE WITH GOOSENECK AND 5TH WHEEL YES
COMPATIBLE WITH OE SKID PLATE YES
DIMENSIONS 76.02" X 20.69" X 19.08"
DRAIN NO
EMBEDDED FITTING THREAD SIZE 1/2" NPT
GROUND CLEARANCE COMPARE TO OE TANK 1.75" LOWER
SENDING UNIT OEM
STRAPS INCLUDED YES
SUMP NO
S&B CAPACITY (APPROXIMATE) 60 GALLONS
TANK TYPE MIDSHIP
TRANSFER PUMP READY YES
WEIGHT DRY 50LBS


VEHICLE FITMENT

YEAR MAKE MODEL ENGINE
2017-2025 FORD F-250 6.7L, DIESEL
2017-2025 FORD F-350 6.7L, DIESEL



EASY RECALIBRATION FOR DISTANCE TO EMPTY

We offer a free service to update the computer in your truck so the Distance to Empty (DTE) displays the accurate range. This works for 2011-2022 Ford trucks. No 2023+ calibration at this time.

COMPATIBLE WITH THE OE SKID PLATE.

If you don't have a skid plate on your truck already, no problem! But if you do, unlike other competitor tanks, we designed the S&B Tank to allow you to reuse the factory skid plate. We also designed a smaller, factory style skid plate to cover the front of the larger S&B Tank.

AFTERMARKET LIFT PUMP

S&B Tanks work with OEM and aftermarket lift pumps. Aftermarket lift pumps(FASS & Airdog) provide more fuel to your diesel engine but face issues at a 1/4 tank fuel level. The S&B Sending Unit allows you to drive to empty with your aftermarket lift pump. Completely plug and play, with no need to modify your OEM tank or sending unit.
