EC Offroad

180AH DCS Dual Lithium Battery

180AH DCS Dual Lithium Battery

Regular price $2,129.00 USD
Regular price Sale price $2,129.00 USD
Sale Sold out
Tax included.

–With solar controller

2 x DCS 90Ah LFP batteries (optimised for engine bay installs)
– Victron Battery Protect SBP-65A
– Max alternator output 160Amps
– Backed by a 3 year under bonnet replacement warranty
– Fully programmable via bluetooth
– Tiny power consumption 1.2mA when engaged
– Suitable for Hilux, Prado, Nissan’s, Mitsubishi’s, Land Rover Defenders etc…
– Not suitable for the Nissan Y62’s

PRE ORDER NOW





– 2 x DCS 90Ah LFP batteries (optimised for engine bay installs)
– Victron Battery Protect SBP-65A
– Max alternator output 160Amps
– Backed by a 3 year under bonnet replacement warranty
– Fully programmable via bluetooth
– Tiny power consumption 1.2mA when engaged
– Suitable for Hilux, Prado, Mitsubishi’s etc…
– With 190Ah of total storage means you have 150Ah x 20% = 38Ah always there for engine cranking. Allowing the upper 80% for deep cycling 152Ah.

Why do we use the latest fully programmable Victron Smart Battery Protects? Because they only have a 1.2mA engaged current draw and the isolators will spend 99% of their service life engaged.
They have bluetooth so via the Victron Connect App you can make quick and easy adjustments, override the isolators and check battery voltages. It also means you don’t need to go pulling the car apart to get to it to check it.
These isolators should be installed as close to the batteries as possible but inside the cabin they are not suitable for engine bay installations.

Specifications:
Nominal Voltage 12.8V
Nominal Capacity (1Hr) 90Ah
Dimensions Length: 260mm, Width: 169mm, Height: 210mm
Weight 10.0 Kg
Cycling voltage 12.8~ 14.6V
Charge voltage 13.8 ~ 14.6V
Float Voltage 13.5 ~ 13.7V
Maximum Charge Current 80A
Recommended Charge Current ≤70A
Maximum Discharge Current ≤200A
BMS (built in) Automatic cell balancing, over discharge/charge
Cell Chemistry DCS 3.2V 7.2Ah Cylindrical (LifePO4)
Cycle Performance 2500 Cycles @ 100% DOD
LCA 750
Engine cranking Max 2500W starter motors
Ingress Protection IP54
Case PP (flame retradent)
Operating temp Range -30 to +80 degrees C
Terminals Top Mount M8 Stainless steel / Copper
Parallel Connections Only Yes
Warranty 3 under bonnet


DOWNLOAD APP (DCS LFP)

DCS Bluetooth Technology powered by DCS LFP, this APP is only for DCS LFP batteries which is based on BLE 4.0 technology.

This App provides comprehensive monitoring for DCS LFP batteries, including:

  • SOC%
  • Battery pack voltage
  • Amp meter – charge and discharge current
  • Battery Management MOSFET temperature
  • Individual Cell Status with balancing indicators.
  • Connectivity distance up to 10 meters.
